Carbon Fabric

Carbon Fibre is a strong material that is also very lightweight. Carbon is five times stronger than steel and twice as stiff. With Carbon Fibre being stronger, stiffer and lighter than steel, it makes the ideal manufacturing material for many parts. Carbon Fibre filaments are supplied in a bundle of between 1,000 and up to 72,000 filaments (the filaments in Carbon are recognised by the letter K, 1K = 1000 filaments 3K = 3000 filaments).

The Benefits

  • High in stiffness
  • High in tensile strength
  • Low weight to strength ratio
  • High in chemical resistance
  • Temperature tolerant to excessive heat
  • Low thermal expansion

Interested in our selection? Contact us today to find out more

What We Offer

The standard range of Woven Carbon Fibre Fabrics available on the market includes plain, twill and satin weave patterns. The earliest fabrics were based on 3k fibres with typical weight around 200g to 285g per square meter. However, with the development of lighter and heavier tows such as 1K, 6k, 12k, 24k and more recently 48k and upwards. The Carbon range of fabric weight has increased from 90g to 1200g. The development of 1k fibre also means fabrics around 90g to 120g can be produced with good quality. Carbon Fibre is very popular in many industries such as Aerospace, Automotive, Military, and Recreational applications.

All the below products can be supplied with a Stabilising web and or Ade-fix where a high-quality surface finish is needed. Please click on the treatment of interest to find out more information.

1K-3K Woven Carbon Fabrics

Datasheet Reference Weight g/m² Weaving Style Warp % Weft % Ends cm Warp Weft Width cm
GG 90 P GG 90 P 93 Plain 50% 50% 7.0 1K 1K 100
GG 120 P GG 120 P * 123 Plain 50% 50% 9.0 1K 1K 100
GG 160 P GG 160 P * 160 Plain 50% 50% 4.0 3K 3K 100
GG 160 T GG 160 T * 160 2/2 Twill 50% 50% 4.0 3K 3K 100
GG 206 P GG 206 P 200 Plain 50% 50% 5 3K 3K 100 / 125
GG 206 T GG 206 T 200 2/2 Twill 50% 50% 5 3K 3K 100
GG 240 P GG 240 P 240 Plain 50% 50% 6 3K 3K 100
GG 240 T GG 240 T 240 2/2 Twill 50% 50% 6 3K 3K 100 / 125
GG 285 T GG 285 T 280 2/2 Twill 50% 50% 7 3K 3K 100

6K Woven Carbon Fabrics

Data Sheet Reference Weight g/m² Weaving Style Warp % Weft % Ends cm Warp Weft Width cm
GG 280 P GG 280 P * 280 Plain 50% 50% 3.5 6K 6K 100
GG 280 T GG 280 T * 280 2/2 Twill 50% 50% 3.5 6K 6K 100
GG 300 P GG 300 P * 300 Plain 50% 50% 4.0 6K 6K 100

12K Woven Carbon Fabrics

Data Sheet Reference Weight g/m² Weaving Style Warp % Weft % Ends cm Warp Weft Width cm
GG 400 P GG 400 P 400 Plain 50% 50% 2.5 12K 12K 100
GG 428 T GG 428 T 428 2/2 Twill 49% 51% Warp - 2.65
Weft - 2.7
12K 12K 100
GG 600 T GG 600 T * 592 2/2 Twill 50% 50% 3.7 12K 12K 100
GG 630 T GG 630 T 632 2/2 Twill 49% 51% Warp - 4.0
Weft - 3.9
12K 12K 100
GG 650 T GG 650 T * 650 2/2 Twill 50% 50% 4.0 12K 12K 100

24K Woven Carbon Fabrics

Data Sheet Reference Weight g/m² Weaving Style Warp % Weft % Ends cm Warp Weft Width cm
GG 800 T GG 800 T * 790 2/2 Twill 51% 49% 2.50 24K 24K 100
GG 1200 T GG 1200 T * 1184 2/2 Twill 50% 50% 3.70 24K 24K 100

* Available to order, please give us a call to find out more about this product
